L6X® – aluminum type 1 cylinders
Luxfer’s all-aluminum SCBA and life-support cylinders have been the industry workhorse in North America since the early 1970s.
Luxfer’s all-aluminum SCBA and life-support cylinders have been the industry workhorse in North America since the early 1970s. Since 1988, Luxfer has manufactured these cylinders from its own proprietary version of 6061-T6 alloy. Now marketed as L6X®, this exclusive aluminum-magnesium-silicon formula was specifically designed by Luxfer metallurgists. More than 40 million L6X all-metal and composite cylinders in service around the world have an exemplary record for safety and dependability. Features and benefits: Up to 40 percent lighter in weight than comparable steel cylinders. Luxfer aluminum SCBA cylinders are non-magnetic and extremely corrosion resistant. Improved durability, fracture toughness and resistance to tearing and cracking. Manufactured in the USA. Notes: All cylinders have non-limited service life as long as they pass required periodic testing. All cylinders are certified to DOT-3AL/TC-3ALM.
SCBA – L6X [EU]
Part number | Standard | Test pressure (bar) | Diameter (mm) | Length (mm) | Weight (kg) | Water volume (l) | Service life (years) | Thread size |
---|---|---|---|---|---|---|---|---|
498/1/Y | PED | 300 | 102 | 394.5 | 2.7 | 2 | NLL | M18 |
906/1/I | TPED | 300 | 90 | 272 | 1.4 | 1 | NLL | 18T |
